eBike battery packs
| Model | TWS-EM-NCM-3610A | TWS-EM-NCM-3610B | TWS-EM-NCM-3613B |
| Cell | 18650 | 21700 | 18650 |
| Dimensions | 312*92*94 (mm) | 290*71*74 (mm) | 387*95*101 (mm) |
| Configuration | 10S4P | 10S2P | 10S5P |
| Capacity (typical) | 10.4Ah | 9.8Ah | 13.0Ah |
| Recommendmotor power | 250W-350W | 250W-350W | 250W-350W |
| Nominal voltage | 36V | 36V | 36V |
| RecommendCharge current | 2A | 3A | 3A |
| Max. continuousdischarge current | 15A | 15A | 20A |
| Waterproof grade | IPX4 | IPX6 | IPX5 |
| Communication | N/A | N/A | UART/CAN |
| Application | eBike | eBike | eBike |
